Non-Reinforced Polyurethane V Belt with Strong Tensile Strength and PVC Grip Top Surface for Superior Grip

  • Non-Reinforced Polyurethane V Belt with Strong Tensile Strength and PVC Grip Top Surface for Superior Grip
Quantità di ordine minimo 1.000
Prezzo 1.8

Contattimi gratis campioni e buoni.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se avete di preoccupazione, forniamo la guida in linea di 24 ore.

x
Dettagli
Materiale pu Materiale interno pu
Durezza 85 riva A della riva A ~90 Profilato Vee
Dimensione del profilo A/13, b/17, c/22 Rinforzo Nessuno
Colore Verde, rosso Durometro 80a, 90a
Superficie superiore PVC Lunghezza del pacchetto 30 metri /rollio
Larghezza a 13 mm Altezza a 8 mm
Larghezza b 17 mm Altezza b 11 mm
Larghezza c 22 mm
Evidenziare

Non-Reinforced Polyurethane V Belt

,

Strong Tensile Strength Super Grip Belt

,

PVC Grip Top Surface PU V Belt
Lasciate un messaggio
Descrizione di prodotto
Non-Reinforced Super Grip Belt
Conveyor PU V Belt with Super Grip / Transmission Polyurethane V Belt Top Green PVC
Manufacturer Overview
Wuxi Jiunai Polyurethane Products Co., Ltd is located in Wuxi City Shitang Bay Mountain Luoshe Town Industrial Park, near to 312 National Road. The company has international-leading polyurethane production lines and advanced testing equipment, maintaining a leading position in production scale, process technology, and technical strength.
Super Grip Belt Features
  • Profile shape: Vee
  • Profile size: A/13, B/17, C/22
  • Reinforcement: None
  • Color: Green, Red
  • Compliancy: RoHS
  • Durometer: 80A, 90A
  • Material: Polyurethane, PVC Top Surface
  • Special Feature: PVC Grip Top Surface
  • Package Length: 30meter/roll
  • Easily welded endless vee belt
Vee-Belt Applications
Widely used in conveying slippery environments and up steep inclines in industrial applications.
Technical Specifications
Specification X(mm) H(mm) Z(mm) M/rolls Reinforced Arabesquitic
A 13 8 3.5 30 · ·
B 17 11 3.5 30 · ·
C 22 14 3.5 30 · ·
D 32 19 3.5 30 · ·
M 8 4 50
Z 10 5 3.5 50 · ·
Product Description
Super grip belts are ideally suited for applications requiring conveying in slippery environments, up steep inclines, or moving easily damaged products. These belts combine the elasticity of an unreinforced V-belt with a super grip surface. The PU Vee Super Grip with top PVC surface is soft and tacky enough to protect delicate cargo while providing excellent grip.
"Quality for keeping going, Credit to win the world"
